ECM Compact HX-2 PID 2 Group Espresso Machine

Professional Performance in a Compact Build

The ECM Compact HX-2 PID from the ECM Commercial Line blends a small footprint with professional espresso performance. Its two ring brew groups work seamlessly with the three included ergonomically angled ECM portafilters, delivering consistent shots every time. Operation is straightforward with automatic dispensing for three cup sizes, optional manual dosing, and a shot counter that tracks extraction time to the second.

✅Two ring brew groups
✅Auto or manual dosing options
✅Integrated shot counter
✅Switchable electronic pre-infusion
✅Quick-opening rotary valves
✅Automatic cleaning programme

Engineered for durability and precision, the Compact HX-2 PID uses a reliable rotary pump, automatic boiler filling, and switchable electronic pre-infusion for optimal extraction. Steam and hot water are delivered quickly through professional rotary valves, keeping workflow smooth during peak hours. Maintenance is easy thanks to an automatic cleaning programme and a service-friendly layout accessible by removing just four screws.

ECM Compact HX-2 PID User Manual

You get all of these freebies when you purchase this machine through Prime Coffee Suppliers:

• Free! Delivery (Worth £95) 5-7 Days pallet delivery form our UK supplier warehouse (delivery date will be booked).

• Free! 1-Year UK Warranty (Worth £60) This includes: All parts that break due to a manufacturing defect will be swapped free of charge for the first year. Labour and call out charges are not included.
• Free! 1 kg Coffee Beans (Worth £30) Start your journey with premium beans on us.

• 3 Trees planted with every order of a ECM Compact HX-2 PID - With our environmental Project through Ecologi. Give back to local projects and the environment when shopping with us!

Features

Two ECM Ring Brew Groups: Featuring a commercial-grade and robust ring-shaped design, these two brew groups ensure an exceptionally consistent and thermally stable extraction for every single espresso shot poured.

Volumetric Dosing: Offering ultimate brewing control, this feature provides three fully programmable coffee buttons per group head, alongside a highly useful manual dosing option for maximum flexibility.

Integrated Shot Timer: Seamlessly built into the machine's interface, this crucial tool provides a precise, clear, and immediate digital readout of the extraction time for every espresso, facilitating perfect shot consistency.

Smart HX® Technology: This innovative heat exchange system constantly and intelligently maintains an optimal and exceptionally stable brew temperature, all while simultaneously delivering a reliably powerful steam performance for texturing milk.

Electronic Pre-Infusion: Ensuring the best possible saturation of the coffee puck, this sophisticated feature is both switchable and fully adjustable, allowing you to fine-tune the crucial wetting and soaking phases of the grounds.

Quick-Opening Rotary Valves: Designed for busy, professional environments, these substantial valves provide an instant, smooth, and highly reliable operation for both the powerful steam wand and the controlled hot water dispenser.

Dual Pressure Gauges: Positioned clearly on the front panel, these two separate gauges allow the operator to monitor the machine's internal performance at a glance, displaying both the crucial boiler pressure and the necessary pump pressure.

Built-In Rotary Pump: Operating with professional-level efficiency, this commercial-grade pump is designed to be remarkably quiet during use and includes a conveniently accessible adjustment screw located on the bottom of the unit.

Automatic Functions: Enhancing user convenience and machine maintenance, the apparatus features essential automation, including reliable automatic boiler filling and a comprehensive automatic cleaning programme for the brew groups.

Full Stainless Steel Construction: Built to last for years in a demanding setting, the entire casing and frame are crafted from highly durable stainless steel.

Specifications of ECM Compact HX-2 PID

• Boiler Type: Heat Exchanger (HX) with Smart HX® Technology
• Boiler Volume: Approx. 9 litres
• Boiler Material: Insulated stainless steel
• Temperature Control: PID temperature controller
• Pump Type: Built-in rotary pump (adjustable from the underside)
• Water Supply: Fixed mains water connection (plumb-in)
• Power: 3000 W (3 kW)
• Voltage: Typically 3-phase, 230 V per phase (other options upon request)
• Productivity: Up to 300 cups per day
• Warm-Up Time: Approx. 25–30 minutes
• Group Head Type: ECM commercial ring brew groups
• Dosing: Volumetric with 3 programmable buttons plus manual mode
• Pre-Infusion: Electronic, adjustable, and switchable
• Steam & Hot Water: Two steam wands and one hot water outlet
• Valves: Professional quick-opening rotary valves
• Pressure Gauges: Boiler pressure gauge + pump pressure gauge
• Dimensions (W × D × H): 650 × 510 × 480 mm (without portafilters)
• Weight: Approx. 58 kg
• Construction: Full stainless steel housing
• Accessories Included:
  • 1× single-spout ECM portafilter
  • 2× double-spout ECM portafilters
  • Two removable drip trays


ECM Video Series – Essential Barista Skills

Level up your coffee-making skills with this 4-part ECM video series! Whether you're just getting started or want to refine your technique, these quick, practical videos will walk you through the basics of working with your ECM machine.

How to Make an Espresso: Learn the fundamentals of pulling the perfect shot every time.

Expansion Valve Adjustment: Fine-tune your pressure settings for optimal espresso extraction on the ECM Puristika.

How to Foam Milk: Master silky smooth milk for your lattes, cappuccinos, and flat whites.

How to Clean the Brew Group: Keep your machine in top shape with proper daily maintenance.

Changing the Group Gasket and Shower Screen: A step-by-step guide to routine maintenance and keeping your espresso tasting its best.
